Mahr 4170032 Vernier Thread Micrometer: 50-75mm
Product Code: 4170032MFGID: 4170032
Brand: MAHR
Product Description
4170032 Mahr Vernier Thread Micrometer: 50-75mm
The Mahr 4170032 Vernier Thread Micrometer has the following specifications:
- Measuring Range: 50-75mm
- Error limit G: 5µm
- Readings: 0.01mm
- Spindle thread pitch: 0.5mm
- Mounting bores for anvils: 3.5mm
Features:
- For measuring pitch, root and outside diameters
- Hard lacquered steel frame, heat insulated
- Spindle is hardened throughout, ground and is also provided which a locking device
- Adjustable anvil
- Spindle and anvil both have a mounting bore to accommodate inter changeable anvils
- Flat end surface of the anvil shank rests on a hardened steel ball which is at the bottom of the mounting bore
- Scales have a satin-chrome finish
- Supplied with: Case
Mahr Precision Vernier Thread Micrometers:
- 4170030 Vernier Thread Micrometer: 0-25mm
- 4170031 Vernier Thread Micrometer: 25-50mm
- 4170032 Vernier Thread Micrometer: 50-75mm
- 4170033 Vernier Thread Micrometer: 75-100mm
- 4170034 Vernier Thread Micrometer: 100-125mm
- 4170035 Vernier Thread Micrometer: 125-150mm
- 4170036 Vernier Thread Micrometer: 150-175mm
- 4170037 Vernier Thread Micrometer: 175-200mm
