Brown and Sharpe Bore GagesBrown and Sharpe INTRIMIK Digital Display Full Set – # 599-290-14

Brown and Sharpe INTRIMIK Digital Display Full Set – # 599-290-14

Name: 599-290-14 B&S INTRIMIK Digital Full Set: 1.58-2.76" - Higher Precision
SKU: 599-290-14

Product Code: 599-290-14

MFGID: 599-290-14

Brand: Brown and Sharpe

Application Range: 1.58-2.76"

Resolution: .0005"

Product Description

599-290-14 Brown and Sharpe Intrimik Full Set: 1.58-2.76″/40-70mm

The Brown and Sharpe 599-290-14 Intrimik Full Set “Capa ? System” and Digital Display has the following specifications:

Range: 1.58-2.76″/40-70mm

Resolution: .00005″/.001mm

Maximum Error: See Individual Range

Repeatability: See Individual Range

EDP: 27534

The Brown and Sharpe Intrimik Full Sets “Capa ? System” with Digital Display include a display for every measuring head.

The Brown and Sharpe 599-290-14 Intrimik Full Set “Capa ? System” and Digital Display is made up of the following:

599-290-200-1 B & S Intrimik w/ Digital Display: 1.58-1.98″/40-50mm

599-290-240-1 B & S Intrimik w/ Digital Display: 1.98-2.38″/50-60mm

599-290-280-1 B & S Intrimik w/ Digital Display: 2.36-2.76″/60-70mm

00860108 Setting Ring: 1.97″

00860109 Setting Ring: 2.75″

00841800 Extension 5.9″

Features:

Standard: DIN 863 T4 (Style C1)

Height of Digits: .275″

LCD Screen

Inch/metric conversion

Floating Zero

Measuring Faces:

.138-.480″: Hardened Steel (770 HV 30)
.430-3.95″: TIN Hard-Coating (2300 HV 5)
3.95-11.80″: Carbide Tipped (1300 HV 5)

3 V Lithium Battery

Autonomy: 1 to 2 a (=2000h/a)

Automatic Shutoff after 10 minutes

IP54 Protected

In-House Calibration Certificate included

Declaration of Conformity included

Display Lock

Digital Interface: Opto-coupled RS-232 interface, bidirectional

Brown And Sharpe Intrimik Full Sets with “Capa ? System” and Digital Display:

599-290-6 Brown and Sharpe Intrimik Full Set: .138-.256″/3.5-6.5mm

599-290-8 Brown and Sharpe Intrimik Full Set: .240-.480″/6-12mm

599-290-10 Brown and Sharpe Intrimik Full Set: .430-.790″/11-20mm

599-290-12 Brown and Sharpe Intrimik Full Set: .790-1.58″/20-40mm

599-290-14 Brown and Sharpe Intrimik Full Set: 1.58-2.76″/40-70mm

599-290-18 Brown and Sharpe Intrimik Full Set: 2.76-3.95″/70-100mm

599-290-20 Brown and Sharpe Intrimik Full Set: 3.95-7.88″/100-200mm
