Brown and Sharpe Bore GagesBrown and Sharpe Intrimik with Digital Display # 599-290-240-1

brown and sharpe 599-290-240-1 intrimiks with digital display inch/metric

Brown and Sharpe Intrimik with Digital Display # 599-290-240-1

Name: 599-290-240-1 B & S Intrimik: 1.98-2.38"/50-60mm - Higher Precision
SKU: 599-290-240-1
Price: 1586.14 USD
Availability: InStock

Product Code: 599-290-240-1

MFGID: 599-290-240-1

Brand: Brown and Sharpe

Range: 1.98-2.38"/50-60mm

Resolution: .00005"/.001mm

Product Description

599-290-240-1 Brown and Sharpe Intrimik: 1.98-2.38″/50-60mm

The Brown and Sharpe 599-290-240-1 Intrimik “Capa ? System” and Digital Display has the following specifications:

Range: 1.98-2.38″/50-60mm

Resolution: .00005″/.001mm

Maximum Error: .00024″

Repeatability: .0002″

Dimension A Cover plate Thickness: .433″

Dimension B Anvil Height: .472″

Dimension C Measuring Depth: 3.85″

EDP: 27514

Features:

Standard: DIN 863 T4 (Style C1)

Height of Digits: .275″

LCD Screen

Inch/metric conversion

Floating Zero

Measuring Faces:

.138-.480″: Hardened Steel (770 HV 30)
.430-3.95″: TIN Hard-Coating (2300 HV 5)
3.95-11.80″: Carbide Tipped (1300 HV 5)

3 V Lithium Battery

Autonomy: 1 to 2 a (=2000h/a)

Automatic Shutoff after 10 minutes

IP54 Protected

In-House Calibration Certificate included

Declaration of Conformity included

Display Lock

Digital Interface: Opto-coupled RS-232 interface, bidirectional

Brown And Sharpe Individual Intrimiks “Capa ? System” with Digital Display:

599-290-28-1 B & S Intrimik w/ Digital Display: .138-.158″/3.5-4.0mm

599-290-30-1 B & S Intrimik w/ Digital Display: .158-.178″/4.0-4.5mm

599-290-32-1 B & S Intrimik w/ Digital Display: .178-.217″/4.5-5.5mm

599-290-34-1 B & S Intrimik w/ Digital Display: .217-.256″/5.5-6.5mm

599-290-35-1 B & S Intrimik w/ Digital Display: .240-.320″/6-8mm

599-290-42-1 B & S Intrimik w/ Digital Display: .320-.400″/8-10mm

599-290-50-1 B & S Intrimik w/ Digital Display: .400-.480″/10-12mm

599-290-60-1 B & S Intrimik w/ Digital Display: .430-.550″/11-14mm

599-290-70-1 B & S Intrimik w/ Digital Display: .550-.670″/14-17mm

599-290-80-1 B & S Intrimik w/ Digital Display: .670-.790″/17-20mm

599-290-100-1 B & S Intrimik w/ Digital Display: .790-.990″/20-25mm

599-290-120-1 B & S Intrimik w/ Digital Display: .990-1.18″/25-30mm

599-290-140-1 B & S Intrimik w/ Digital Display: 1.18-1.38″/30-35mm

599-290-160-1 B & S Intrimik w/ Digital Display: 1.38-1.58″/35-40mm

599-290-200-1 B & S Intrimik w/ Digital Display: 1.58-1.98″/40-50mm

599-290-240-1 B & S Intrimik w/ Digital Display: 1.98-2.38″/50-60mm

599-290-280-1 B & S Intrimik w/ Digital Display: 2.36-2.76″/60-70mm

599-290-320-1 B & S Intrimik w/ Digital Display: 2.76-3.16″/70-80mm

599-290-360-1 B & S Intrimik w/ Digital Display: 3.15-3.55″/80-90mm

599-290-400-1 B & S Intrimik w/ Digital Display: 3.55-3.95″/90-100mm

599-290-420-1 B & S Intrimik w/ Digital Display: 3.95-4.94″/100-125mm

599-290-440-1 B & S Intrimik w/ Digital Display: 4.94-5.90″/125-150mm

599-290-460-1 B & S Intrimik w/ Digital Display: 5.90-6.90″/150-175mm

599-290-480-1 B & S Intrimik w/ Digital Display: 6.90-7.88″/175-200mm

599-290-500-1 B & S Intrimik w/ Digital Display: 7.88-8.86″/200-225mm

599-290-520-1 B & S Intrimik w/ Digital Display: 8.86-9.85″/225-250mm

599-290-540-1 B & S Intrimik w/ Digital Display: 9.85-10.84″/250-275mm

599-290-560-1 B & S Intrimik w/ Digital Display: 10.84-11.80″/275-300mm
