  • Product Code: #599-290-50-1

    Intrimik with Digital Display # 599-290-50-1

    Range: .400-.480"/10-12mm

    Resolution: .00005"/.001mm

    Price: $1,058.00 $780.00
    Lowest Price Guaranteed!
    Quantity

    Product Description

    599-290-50-1 Brown and Sharpe Intrimik: .400-.480"/10-12mm

    The Brown and Sharpe 599-290-50-1 Intrimik "Capa µ System" and Digital Display has the following specifications:

    • Range: .400-.480"/10-12mm
    • Resolution: .00005"/.001mm
    • Maximum Error: .00016"
    • Repeatability: .00016"
    • Dimension A Cover plate Thickness: .139"
    • Dimension B Anvil Height: .059"
    • Dimension C Measuring Depth: 2.17"
    • EDP: 27505

    Features:

    • Standard: DIN 863 T4 (Style C1)
    • Height of Digits: .275"
    • LCD Screen
    • Inch/metric conversion
    • Floating Zero
    • Measuring Faces:
      • .138-.480": Hardened Steel (770 HV 30)
      • .430-3.95": TIN Hard-Coating (2300 HV 5)
      • 3.95-11.80": Carbide Tipped (1300 HV 5)
    • 3 V Lithium Battery
    • Autonomy: 1 to 2 a (=2000h/a)
    • Automatic Shutoff after 10 minutes
    • IP54 Protected
    • In-House Calibration Certificate included
    • Declaration of Conformity included
    • Display Lock
    • Digital Interface: Opto-coupled RS-232 interface, bidirectional

    Brown And Sharpe Individual Intrimiks "Capa µ System" with Digital Display:

    • 599-290-28-1 B & S Intrimik w/ Digital Display: .138-.158"/3.5-4.0mm
    • 599-290-30-1 B & S Intrimik w/ Digital Display: .158-.178"/4.0-4.5mm
    • 599-290-32-1 B & S Intrimik w/ Digital Display: .178-.217"/4.5-5.5mm
    • 599-290-34-1 B & S Intrimik w/ Digital Display: .217-.256"/5.5-6.5mm
    • 599-290-35-1 B & S Intrimik w/ Digital Display: .240-.320"/6-8mm
    • 599-290-42-1 B & S Intrimik w/ Digital Display: .320-.400"/8-10mm
    • 599-290-50-1 B & S Intrimik w/ Digital Display: .400-.480"/10-12mm
    • 599-290-60-1 B & S Intrimik w/ Digital Display: .430-.550"/11-14mm
    • 599-290-70-1 B & S Intrimik w/ Digital Display: .550-.670"/14-17mm
    • 599-290-80-1 B & S Intrimik w/ Digital Display: .670-.790"/17-20mm
    • 599-290-100-1 B & S Intrimik w/ Digital Display: .790-.990"/20-25mm
    • 599-290-120-1 B & S Intrimik w/ Digital Display: .990-1.18"/25-30mm
    • 599-290-140-1 B & S Intrimik w/ Digital Display: 1.18-1.38"/30-35mm
    • 599-290-160-1 B & S Intrimik w/ Digital Display: 1.38-1.58"/35-40mm
    • 599-290-200-1 B & S Intrimik w/ Digital Display: 1.58-1.98"/40-50mm
    • 599-290-240-1 B & S Intrimik w/ Digital Display: 1.98-2.38"/50-60mm
    • 599-290-280-1 B & S Intrimik w/ Digital Display: 2.36-2.76"/60-70mm
    • 599-290-320-1 B & S Intrimik w/ Digital Display: 2.76-3.16"/70-80mm
    • 599-290-360-1 B & S Intrimik w/ Digital Display: 3.15-3.55"/80-90mm
    • 599-290-400-1 B & S Intrimik w/ Digital Display: 3.55-3.95"/90-100mm
    • 599-290-420-1 B & S Intrimik w/ Digital Display: 3.95-4.94"/100-125mm
    • 599-290-440-1 B & S Intrimik w/ Digital Display: 4.94-5.90"/125-150mm
    • 599-290-460-1 B & S Intrimik w/ Digital Display: 5.90-6.90"/150-175mm
    • 599-290-480-1 B & S Intrimik w/ Digital Display: 6.90-7.88"/175-200mm
    • 599-290-500-1 B & S Intrimik w/ Digital Display: 7.88-8.86"/200-225mm
    • 599-290-520-1 B & S Intrimik w/ Digital Display: 8.86-9.85"/225-250mm
    • 599-290-540-1 B & S Intrimik w/ Digital Display: 9.85-10.84"/250-275mm
    • 599-290-560-1 B & S Intrimik w/ Digital Display: 10.84-11.80"/275-300mm
  •
