  • Product Code: #54-565-228

    Ultima Bore Gage Individual Head # 54-565-228

    Range/Size: 5.9-6.3"/150-160mm

    Graduations: .00001"/.001mm

    Price: $1,666.00 $1,566.04
    Lowest Price Guaranteed
    Quantity

    Product Description

    54-565-228 Fowler Ultima Bore Gage Individual Head: 5.9-6.3"/150-160mm

    The Fowler/Bowers 54-565-228 Ultima Head has the following specifications:

    • Range: 5.9-6.3"/150-160mm
    • Accuracy: .00006"/.0015mm
    • Measuring Depth: 3.15"/80mm

    Special Features:

    • Greater accuracy
    • Utilizes Bowers' "FASTFIT" measuring heads
    • Setting rings manufactured to DIN Standard 2250 part 2.
    • Extended head ranges (above 14mm) for greater flexibility and cost-effective measurement.
    • All 2-6mm sets supplied as standard with depth-stop.

    Features:

    • Total Measuring Range: .078-12.3"/2-310mm
    • Resolution: .00001"/.0001mm
    • Constant spring pressure ensures top repeatability.
    • Positive feel when heads self-center in the bore.
    • Fastfit measuring heads for rapid replacement.
    • UKAS certificates standard for all measuring heads.
    • UKAS certificates standard for all setting rings.
    • Ceramic anvils on heads above .472"/12mm
    • Blind-bore measurement standard above .472"/12mm
    • Possible to connect several probe holders to one single readout to measure different bore sizes at one measuring station.
    • Depth stops available for all heads.
    • Extensions available for deep bore measurement.

    Fowler/Bowers Ultima Bore Gage Individual Heads:

    • 54-565-201 Fowler/Bowers Ultima Bore Gage Individual Head: .078-.098"/2.0-2.5mm
    • 54-565-202 Fowler/Bowers Ultima Bore Gage Individual Head: .098-.118"/2.5-3.0mm
    • 54-565-203 Fowler/Bowers Ultima Bore Gage Individual Head: .118-.157"/3-4mm
    • 54-565-204 Fowler/Bowers Ultima Bore Gage Individual Head: .157-.197"/4-5mm
    • 54-565-205 Fowler/Bowers Ultima Bore Gage Individual Head: .197-.236"/5-6mm
    • 54-565-206 Fowler/Bowers Ultima Bore Gage Individual Head: .236-.315"/6-8mm
    • 54-565-207 Fowler/Bowers Ultima Bore Gage Individual Head: .315-.393"/8-10mm
    • 54-565-208 Fowler/Bowers Ultima Bore Gage Individual Head: .393-.472"/10-12mm
    • 54-565-209 Fowler/Bowers Ultima Bore Gage Individual Head: .472-.550"/12-14mm
    • 54-565-210 Fowler/Bowers Ultima Bore Gage Individual Head: .550-.670"/14-17mm
    • 54-565-211 Fowler/Bowers Ultima Bore Gage Individual Head: .670-.787"/17-20mm
    • 54-565-212 Fowler/Bowers Ultima Bore Gage Individual Head: .787-.945"/20-24mm
    • 54-565-213 Fowler/Bowers Ultima Bore Gage Individual Head: .945-1.10"/24-28mm
    • 54-565-214 Fowler/Bowers Ultima Bore Gage Individual Head: 1.10-1.26"/28-32mm
    • 54-565-215 Fowler/Bowers Ultima Bore Gage Individual Head: 1.26-1.50"/32-38mm
    • 54-565-216 Fowler/Bowers Ultima Bore Gage Individual Head: 1.50-1.73"/38-44mm
    • 54-565-217 Fowler/Bowers Ultima Bore Gage Individual Head: 1.73-1.97"/44-50mm
    • 54-565-218 Fowler/Bowers Ultima Bore Gage Individual Head: 1.97-2.36"/50-60mm
    • 54-565-219 Fowler/Bowers Ultima Bore Gage Individual Head: 2.36-2.75"/60-70mm
    • 54-565-220 Fowler/Bowers Ultima Bore Gage Individual Head: 2.75-3.15"/70-80mm
    • 54-565-221 Fowler/Bowers Ultima Bore Gage Individual Head: 3.15-3.54"/80-90mm
    • 54-565-222 Fowler/Bowers Ultima Bore Gage Individual Head: 3.54-3.94"/90-100mm
    • 54-565-223 Fowler/Bowers Ultima Bore Gage Individual Head: 3.94-4.33"/100-110mm
    • 54-565-224 Fowler/Bowers Ultima Bore Gage Individual Head: 4.33-4.72"/110-120mm
    • 54-565-225 Fowler/Bowers Ultima Bore Gage Individual Head: 4.72-5.12"/120-130mm
    • 54-565-226 Fowler/Bowers Ultima Bore Gage Individual Head: 5.12-5.51"/130-140mm
    • 54-565-227 Fowler/Bowers Ultima Bore Gage Individual Head: 5.51-5.90"/140-150mm
    • 54-565-228 Fowler/Bowers Ultima Bore Gage Individual Head: 5.90-6.30"/150-160mm
    • 54-565-229 Fowler/Bowers Ultima Bore Gage Individual Head: 6.30-6.69"/160-170mm
    • 54-565-230 Fowler/Bowers Ultima Bore Gage Individual Head: 6.69-7.09"/170-180mm
    • 54-565-231 Fowler/Bowers Ultima Bore Gage Individual Head: 7.09-7.48"/180-190mm
    • 54-565-232 Fowler/Bowers Ultima Bore Gage Individual Head: 7.48-7.87"/190-200mm
    • 54-565-233 Fowler/Bowers Ultima Bore Gage Individual Head: 7.87-8.27"/200-210mm
    • 54-565-234 Fowler/Bowers Ultima Bore Gage Individual Head: 8.27-8.66"/210-220mm
    • 54-565-235 Fowler/Bowers Ultima Bore Gage Individual Head: 8.66-9.05"/220-230mm
    • 54-565-236 Fowler/Bowers Ultima Bore Gage Individual Head: 9.05-9.45"/230-240mm
    • 54-565-237 Fowler/Bowers Ultima Bore Gage Individual Head: 9.45-9.84"/240-250mm
    • 54-565-238 Fowler/Bowers Ultima Bore Gage Individual Head: 9.84-10.23"/250-260mm
    • 54-565-239 Fowler/Bowers Ultima Bore Gage Individual Head: 10.23-10.63"/260-270mm
    • 54-565-240 Fowler/Bowers Ultima Bore Gage Individual Head: 10.63-11.02"/270-280mm
    • 54-565-241 Fowler/Bowers Ultima Bore Gage Individual Head: 11.02-11.41"/280-290mm
    • 54-565-242 Fowler/Bowers Ultima Bore Gage Individual Head: 11.41-11.81"/290-300mm
    • 54-565-243 Fowler/Bowers Ultima Bore Gage Individual Head: 11.81-12.20"/300-310mm

    The Fowler/Bowers 54-565-228 ultima bore gage head can be customized to be able to measure grooves, gears, threads, splines and deep bores. Please contact one of our inside sales representatives for assistance.

  •
