Fowler 54-565-232 Ultima Bore Gage Head: 7.48-7.875″

Fowler 54-565-232 Ultima Bore Gage Head: 7.48-7.875″

Product Code: 54-565-232

MFGID: 54-565-232

Brand: Fowler

Range/Size: 7.48-7.875"/190-200mm

Graduations: .00001"/.001mm

Product Description

54-565-232 Fowler Ultima Bore Gage Individual Head: 7.48-7.875″/190-200mm

The Fowler/Bowers 54-565-232 Ultima Head has the following specifications:

Range: 7.48-7.875″/190-200mm
Accuracy: .00006″/.0015mm
Measuring Depth: 3.15″/80mm

Special Features:

Greater accuracy
Utilizes Bowers’ “FASTFIT” measuring heads
Setting rings manufactured to DIN Standard 2250 part 2.
Extended head ranges (above 14mm) for greater flexibility and cost-effective measurement.
All 2-6mm sets supplied as standard with depth-stop.

Features:

Total Measuring Range: .078-12.3″/2-310mm
Resolution: .00001″/.0001mm
Constant spring pressure ensures top repeatability.
Positive feel when heads self-center in the bore.
Fastfit measuring heads for rapid replacement.
UKAS certificates standard for all measuring heads.
UKAS certificates standard for all setting rings.
Ceramic anvils on heads above .472″/12mm
Blind-bore measurement standard above .472″/12mm
Possible to connect several probe holders to one single readout to measure different bore sizes at one measuring station.
Depth stops available for all heads.
Extensions available for deep bore measurement.

Fowler/Bowers Ultima Bore Gage Individual Heads:

54-565-201 Fowler/Bowers Ultima Bore Gage Individual Head: .078-.098″/2.0-2.5mm
54-565-202 Fowler/Bowers Ultima Bore Gage Individual Head: .098-.118″/2.5-3.0mm
54-565-203 Fowler/Bowers Ultima Bore Gage Individual Head: .118-.157″/3-4mm
54-565-204 Fowler/Bowers Ultima Bore Gage Individual Head: .157-.197″/4-5mm
54-565-205 Fowler/Bowers Ultima Bore Gage Individual Head: .197-.236″/5-6mm
54-565-206 Fowler/Bowers Ultima Bore Gage Individual Head: .236-.315″/6-8mm
54-565-207 Fowler/Bowers Ultima Bore Gage Individual Head: .315-.393″/8-10mm
54-565-208 Fowler/Bowers Ultima Bore Gage Individual Head: .393-.472″/10-12mm
54-565-209 Fowler/Bowers Ultima Bore Gage Individual Head: .472-.550″/12-14mm
54-565-210 Fowler/Bowers Ultima Bore Gage Individual Head: .550-.670″/14-17mm
54-565-211 Fowler/Bowers Ultima Bore Gage Individual Head: .670-.787″/17-20mm
54-565-212 Fowler/Bowers Ultima Bore Gage Individual Head: .787-.945″/20-24mm
54-565-213 Fowler/Bowers Ultima Bore Gage Individual Head: .945-1.10″/24-28mm
54-565-214 Fowler/Bowers Ultima Bore Gage Individual Head: 1.10-1.26″/28-32mm
54-565-215 Fowler/Bowers Ultima Bore Gage Individual Head: 1.26-1.50″/32-38mm
54-565-216 Fowler/Bowers Ultima Bore Gage Individual Head: 1.50-1.73″/38-44mm
54-565-217 Fowler/Bowers Ultima Bore Gage Individual Head: 1.73-1.97″/44-50mm
54-565-218 Fowler/Bowers Ultima Bore Gage Individual Head: 1.97-2.36″/50-60mm
54-565-219 Fowler/Bowers Ultima Bore Gage Individual Head: 2.36-2.75″/60-70mm
54-565-220 Fowler/Bowers Ultima Bore Gage Individual Head: 2.75-3.15″/70-80mm
54-565-221 Fowler/Bowers Ultima Bore Gage Individual Head: 3.15-3.54″/80-90mm
54-565-222 Fowler/Bowers Ultima Bore Gage Individual Head: 3.54-3.94″/90-100mm
54-565-223 Fowler/Bowers Ultima Bore Gage Individual Head: 3.94-4.33″/100-110mm
54-565-224 Fowler/Bowers Ultima Bore Gage Individual Head: 4.33-4.72″/110-120mm
54-565-225 Fowler/Bowers Ultima Bore Gage Individual Head: 4.72-5.12″/120-130mm
54-565-226 Fowler/Bowers Ultima Bore Gage Individual Head: 5.12-5.51″/130-140mm
54-565-227 Fowler/Bowers Ultima Bore Gage Individual Head: 5.51-5.90″/140-150mm
54-565-228 Fowler/Bowers Ultima Bore Gage Individual Head: 5.90-6.30″/150-160mm
54-565-229 Fowler/Bowers Ultima Bore Gage Individual Head: 6.30-6.69″/160-170mm
54-565-230 Fowler/Bowers Ultima Bore Gage Individual Head: 6.69-7.09″/170-180mm
54-565-231 Fowler/Bowers Ultima Bore Gage Individual Head: 7.09-7.48″/180-190mm
54-565-232 Fowler/Bowers Ultima Bore Gage Individual Head: 7.48-7.87″/190-200mm
54-565-233 Fowler/Bowers Ultima Bore Gage Individual Head: 7.87-8.27″/200-210mm
54-565-234 Fowler/Bowers Ultima Bore Gage Individual Head: 8.27-8.66″/210-220mm
54-565-235 Fowler/Bowers Ultima Bore Gage Individual Head: 8.66-9.05″/220-230mm
54-565-236 Fowler/Bowers Ultima Bore Gage Individual Head: 9.05-9.45″/230-240mm
54-565-237 Fowler/Bowers Ultima Bore Gage Individual Head: 9.45-9.84″/240-250mm
54-565-238 Fowler/Bowers Ultima Bore Gage Individual Head: 9.84-10.23″/250-260mm
54-565-239 Fowler/Bowers Ultima Bore Gage Individual Head: 10.23-10.63″/260-270mm
54-565-240 Fowler/Bowers Ultima Bore Gage Individual Head: 10.63-11.02″/270-280mm
54-565-241 Fowler/Bowers Ultima Bore Gage Individual Head: 11.02-11.41″/280-290mm
54-565-242 Fowler/Bowers Ultima Bore Gage Individual Head: 11.41-11.81″/290-300mm
54-565-243 Fowler/Bowers Ultima Bore Gage Individual Head: 11.81-12.20″/300-310mm

The Fowler/Bowers 54-565-232 ultima bore gage head can be customized to be able to measure grooves, gears, threads, splines and deep bores. Please contact one of our inside sales representatives for assistance.
