PRODUCT CODE: 4190311

Self-Centering Inside Micrometer – # 4190311

Measuring Range: 8-10mm

Measuring Depth: 58 / (133**)mm

Price: $559 $531.05
Lowest Price Guaranteed
Quantity

Product Description

4190311 Mahr Self-Centering Inside Micrometer: 8-10mm

The Mahr 4190311 Self-Centering Inside Micrometer has the following specifications:

  • Measuring Range: 8-10mm
  • Measuring Depth: 58 / (133**)mm
  • Readings: 0.001mm
  • Error Limit G*: 4?m

Features:

  • Scales with satin-chrome finish
  • Spindle is hardened throughout and ground
  • Rapid drive with integrated ratchet
  • Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120°
  • Anvils from 12 mm are carbide tipped
  • From 12 mm the anvils can be used to measure to the bottom of a bore
  • From 40 mm all measuring heads are made from aluminum to reduce weight
  • Supplied with: Case and operating instructions

Mahr Self-Centering Inside Micrometers:

  • 4190310 Self-Centering Inside Micrometer: 6-8mm
  • 4190311 Self-Centering Inside Micrometer: 8-10mm
  • 4190312 Self-Centering Inside Micrometer: 10-12mm
  • 4190313 Self-Centering Inside Micrometer: 12-16mm
  • 4190314 Self-Centering Inside Micrometer: 16-20mm
  • 4190315 Self-Centering Inside Micrometer: 20-25mm
  • 4190316 Self-Centering Inside Micrometer: 25-30mm
  • 4190317 Self-Centering Inside Micrometer: 30-40mm
  • 4190319 Self-Centering Inside Micrometer: 50-60mm
  • 4190320 Self-Centering Inside Micrometer: 60-70mm
  • 4190012 Self-Centering Inside Micrometer: 70-85mm
  • 4190013 Self-Centering Inside Micrometer: 85-100mm
  • 4190014 Self-Centering Inside Micrometer: 100-125mm
  • 4190015 Self-Centering Inside Micrometer: 125-150mm
  • 4190016 Self-Centering Inside Micrometer: 150-175mm
  • 4190017 Self-Centering Inside Micrometer: 175-200mm

Mahr Self-Centering Inside Micrometer Sets:

  • 4190350 Self-Centering Inside Micrometer Set: 6-12mm
  • 4190351 Self-Centering Inside Micrometer Set: 12-20mm
  • 4190352 Self-Centering Inside Micrometer Set: 20-50mm
  • 4190353 Self-Centering Inside Micrometer Set: 50-100mm
