Mahr Digital Depth Gages – MarCal 30 EWN
Product Code: 4126512MFGID: 4126512
Brand: MAHR
Product Description
4126512 Mahr Digital Depth Gage – MarCal 30 EWN: 0-100mm/4″
The Mahr 4126512 Digital Depth Gage – MarCal 30 EWN has the following specifications:
- Measuring Range: 0-100mm/4″
- Length of Cross Beam: 85mm/3.34″
- Resolution: 0.01mm/.0005″
- Error limit: 0.03mm.
- Version: A
Applications:
- Ideal for measuring the width of grooves and distances between grooves.
Functions:
- ON/OFF RESET Set display to zero mm/inch.
- PRESET enter a numerical value >Reference-Lock/Unlock.
- DATA Data transmission via connection cable.
- Auto-ON/OFF.
Features:
- Immediate measurement due to the Reference system.
- Excellent resistance against dust, coolants and lubricants,protection class IP67.
- MarConnect data output,choose alternatively: USB, OPTO RS232C or Digimatic.
- Dirt wipers are integrated in the slide.
- Life of the battery up to 3 years.
- Max measuring speed 2,5 m/s (100″/s).
- High contrast LCD with 8.5mm high digits.
- Beam and cross beam are made of hardened stainless steel.
- Locking screw.
- Supplied with: Case, battery, operating instructions. Version A: Anvils 30 ENt (1 mm), 902 and 903.
Digital Depth Gages MarCal 30 EWN
