Brown and Sharpe Height GagesMICRO-HITE 900 # 00730075

MICRO-HITE 900 # 00730075

Name: 00730075 Brown & Sharpe MICRO-HITE 900: 0-36"/900mm - Higher Precision
SKU: 00730075

Product Code: 00730075

MFGID: 00730075

Brand: Brown and Sharpe

Measuring Range: 0-36"/900mm

Maximum permissible error: 2+2L/1000μm

Request Quote

Product Description

00730075 Brown & Sharpe MICRO-HITE 900: 0-36″/900mm

The Brown & Sharpe 00730075 MICRO-HITE 900 has the following specifications:

Measuring Range: 0-36″/900mm
Application Range: 0-42″/1075mm
Measuring Force: 1.6 ± 0.25 N
Max Permissible error (?m), [L en mm]: 2+2L/1000?m
Repeatability limit: On Surface: ? 1; On Arc: ? 1
Max. Perp. Error with IG13 Probe (?m): Frontal: 9 – Lateral: 9
Max. Perp. Error, Mechanical (?m): Frontal: 11
Autonomy (h): 8
Trigger Force (N): 1.6 ± 0.25
Resolution: 0.0001/.001/.01mm – 0.00001/.0001/.001″
Screen: (L x H, mm): 84×152
Keyboard: Backlit
Zero: Fixed
Coefficient of Linear Expansion: 11.5 x 10-6 K-1
Integrated Fine Adjustment
Weight: 45kg/99lbs
Power Supply: External power supply or integrated rechargeable battery
Units: mm/in
EDP: 76641

Features:

For workshops and laboratories
Manual displacements
Air cushion system
With or without fine adjustment device
Adjustable panel
Color & touch screen
Included SCS certificate
1D & 2D measurement modes
Spheroidal cast iron base with 3 support fields

This high-end instrument is intuitive due to a clear and refined user philosophy of its embedded software and allows measurements in 1 or 2 coordinate directions. Universal machine developed for workshops and for laboratories that can be integrated as close as possible to the user. Indeed, the robustness of its cast iron base and frame makes it a reliable instrument that guarantees an excellent repeatability and precision in any kind of conditions.

With the exception of the 1D basis functions, it is equipped with advanced functions (angle, programming, tolerancing, 2D, …) and turns it into a metrological multi-user asset, that replaces the most conventional measuring tools.

With the integrated patented QUICKCENTER technology, the height gauge gives clear indications not only when capturing simple points but it becomes a proven advantage for the determination of the culmination points.

Each MICRO-HITE is delivered with a free calibration certificate SCS (Swiss Calibration Service) avoiding any additional extra cost due to a re-certification of the instrument directly after purchase.

Below is a video for the 00730075 MICRO-HITE and links to different MICRO-HITE sizes.

Brown & Sharpe MICRO-HITE Height Gages
