  • Product Code: #141-212

    Carbide Tipped Inside Micrometer # 141-212

    Range: 50 - 300mm

    Travel of Micrometer Head: 13mm

    Price: $374.00 $321.64
    Lowest Price Guaranteed
    Quantity

    Product Description

    141-212 Mitutoyo Carbide Tipped Inside Micrometer - Metric

    The Mitutoyo 141-212 Carbide Tipped Inside Micrometer - Metric has the following specifications:

    • Range: 50 - 300mm
    • Travel of Micrometer Head: 13mm
    • Accuracy: +/-(6+L/50)μm  L=Maximum measuring length (mm) Fraction rounded up
    • Graduation: 0.01mm or .001"
    • With 5 rods

    Features:

    • With locking clamp.
    • Each interchangeable rod is marked with its measuring range.
    • The sizes of interchangeable rods can be adjusted with spacing collars.
    • Both micrometer head and furnished rods are satin-chrome finished throughout.
    • Supplied in fitted plastic case. Over 1000mm / 40" supplied in wooden case.

    Carbide Tipped Inside Micrometers - Interchangeable-Rod Type - Metric

    • 141-003: Carbide Tipped Inside Micrometer: 25 - 32mm
    • 141-103: Carbide Tipped Inside Micrometer: 25 - 50mm
    • 141-027: Carbide Tipped Inside Micrometer: 50 - 63mm
    • 141-211: Carbide Tipped Inside Micrometer: 50 - 200mm
    • 141-212: Carbide Tipped Inside Micrometer: 50 - 300mm
    • 141-011: Carbide Tipped Inside Micrometer: 200 - 225mm

    Inside Micrometers - Interchangeable-Rod Type - Metric

    • 141-001: Inside Micrometer: 25-32mm
    • 141-101: Inside Micrometer: 25-50mm
    • 141-025: Inside Micrometer: 50-63mm
    • 141-205: Inside Micrometer: 50-200mm
    • 141-206: Inside Micrometer: 50-300mm
    • 141-009: Inside Micrometer: 200-225mm
    • 141-117: Inside Micrometer: 200-500mm
    • 141-118: Inside Micrometer: 200-1000mm
  •
