Mitutoyo 141-009 Inside Micrometer: 200-225mm
Product Code: 141-009MFGID: 141-009
Brand: Mitutoyo
Product Description
141-009 Mitutoyo Inside Micrometer: 200-225mm
The Mitutoyo 141-009 Inside Micrometer – Metric has the following specifications:
- Range: 200-225mm
- Travel of Micrometer Head: 25mm
- Accuracy: +/-(6+L/50)?m L=Maximum measuring length (mm) Fraction rounded up
- Graduation: 0.01mm or .001″
- Micrometer Head only
Features:
- With locking clamp.
- Each interchangeable rod is marked with its measuring range.
- The sizes of interchangeable rods can be adjusted with spacing collars.
- Both micrometer head and furnished rods are satin-chrome finished throughout.
- Supplied in fitted plastic case. Over 1000mm / 40″ supplied in wooden case.
Inside Micrometers – Interchangeable-Rod Type – Metric
- 141-001 Inside Micrometer: 25-32mm
- 141-101 Inside Micrometer: 25-50mm
- 141-025 Inside Micrometer: 50-63mm
- 141-205 Inside Micrometer: 50-200mm
- 141-206 Inside Micrometer: 50-300mm
- 141-009 Inside Micrometer: 200-225mm
- 141-117 Inside Micrometer: 200-500mm
- 141-118 Inside Micrometer: 200-1000mm
Carbide Tipped Inside Micrometers – Interchangeable-Rod Type – Metric
- 141-003 Carbide Tipped Inside Micrometer: 25-32mm
- 141-103 Carbide Tipped Inside Micrometer: 25-50mm
- 141-027 Carbide Tipped Inside Micrometer: 50-63mm
- 141-211 Carbide Tipped Inside Micrometer: 50-200mm
- 141-212 Carbide Tipped Inside Micrometer: 50-300mm
- 141-011 Carbide Tipped Inside Micrometer: 200-225mm
