Outside Micrometer # 105-411

105-411 Outside Micrometer - with Extension Anvil Collars: 1300-1400mm

The Mitutoyo 105-411 Outside Micrometer has the following specifications:

• Range: 1300-1400mm
• Extension Collars: 50mm
• Accuracy: ±(6+R/75)Ìm, R=max. range (mm)
• Mass(g): 8.50

Features:

• Wide measuring range with extension anvil collars.
• 50mm spindle stroke.
• With Ratchet Stop for constant force.
• Supplied with zero-setting standards bar for each range.
• Square and round pipes are combined for light weight and rigid frame (for models over 1000mm range).
• Workpiece stopper (for models over 1000mm range).
• Supplied in a fitted wooden case.

Technical Data

• Graduation: 0.01mm
• Flatness: 1.3µm
• Parallelism: (2+R/100)µm, R=max. range (mm)
• Measuring faces: Carbide tipped

Mitutoyo Outside Micrometers - with Extension Anvil Collars - Metric:

• 105-103 Outside Micrometer: 500-600mm
• 105-104 Outside Micrometer: 600-700mm
• 105-105 Outside Micrometer: 700-800mm
• 105-106 Outside Micrometer: 800-900mm
• 105-107 Outside Micrometer: 900-1000mm
• 105-408 Outside Micrometer: 1000-1100mm
• 105-409 Outside Micrometer: 1100-1200mm
• 105-418 Outside Micrometer: 1000-1200mm
• 105-410 Outside Micrometer: 1200-1300mm
• 105-411 Outside Micrometer: 1300-1400mm
• 105-419 Outside Micrometer: 1200-1400mm
• 105-412 Outside Micrometer: 1400-1500mm
• 105-413 Outside Micrometer: 1500-1600mm
• 105-420 Outside Micrometer: 1400-1600mm
• 105-414 Outside Micrometer: 1600-1700mm
• 105-415 Outside Micrometer: 1700-1800mm
• 105-421 Outside Micrometer: 1600-1800mm
• 105-416 Outside Micrometer: 1800-1900mm
• 105-417 Outside Micrometer: 1900-2000mm
• 105-422 Outside Micrometer: 1800-2000mm
