  • Product Code: #201-161

    Dial Snap Gage # 201-161

    Measuring force: 15+/-3N

    Range: 10 - 11"

    Price: $780.00 $670.80

    Lowest Price Guaranteed

    Quantity

    Product Description

    201-161 Mitutoyo Dial Snap Gage - 10 - 11"

    The Mitutoyo 201-161 Dial Snap Gage - has the following specifications:

    • Range: 10 - 11"
    • Measuring force: .00025" or less
    • Parallelism: .00025" or less
    • Recommended dial indicator (optional): 2803SB-10 (.0001" reading)
    • Accuracy: Refer to the list of specifications
    • Anvil retracting stroke: .078" / 2mm
    • Anvil positioning range: 1" / 25mm
    • Anvil flatness: .00004" / 1?m

    Features:

    • Designed for quick go/no-go judgment of diameters of cylinders and shafts in machining processes.
    • Dial indicator is optional.
    • Wide (.53 x .47" / 13.5 x 12mm), flat carbide anvils
    • Both front edges of the anvil are chamfered for easy insertion.
