PRODUCT CODE: 78MXTZ-200

78MXT Mechanical Bore Gage # 78MXTZ-200

Range: 175-200mm

Graduations: .005mm

Price: $3331 $3131.14
Lowest Price Guaranteed
Quantity

Product Description

78MXTZ-200 Starrett Mechanical Bore Gage: 175-200mm

The Starrett 78MXTZ-200 Mechanical Bore Micrometer has the following specifications:

  • Range: 175-200mm
  • Graduations: .005mm
  • Accuracy: .007mm
  • Measuring Depth: 115mm
  • EDP: 67868

The 78XT Series Internal Micrometers feature extended travel and fixed measuring anvils so there is not more swapping out anvils. The ground contact points seat the internal micrometer faster and more accurately than the spherical contacts found in other gages. These rugged and accurate internal micrometers are available individually or in economical sets from .080-12″/2-300mm.

The Starrett 78MXTZ-200 Mechanical Bore Gage is made up of the following:

  • Mechanical Bore Gage Readout
  • Measuring Head: 175-200mm
  • Setting Ring: 175mm

Features:

  • Wide measurement range without changing anvils
  • Graduations:
    • 2-6mm: .0025mm
    • 6-300mm: .005mm
  • Tungsten carbide measuring faces on all 3-point heads above 1/2″ (12.5mm)
  • Ratchet stop ensures consistent measurements
  • Self-centering contacts for true readings
  • Blind bore measuring capability above 1/2″ (12.5mm) diameter
  • Extensions available up to 6″ (150mm) for deep hole measuring
  • Setting rings included
  • Depth stop/collar also available for .080″- .250″ (1-6mm) range
  • Each micrometer bore gage is furnished in a case, complete with setting ring, contacts, wrenches, and instructions.

Starrett 78MXT Mechanical Bore Gages – Metric:

Individual Bore Gages:

  • 78MXTZ-8     Mechanical 3-Point Bore Gage: 6-8mm
  • 78MXTZ-10   Mechanical 3-Point Bore Gage: 8-10mm
  • 78MXTZ-12.5 Mechanical 3-Point Bore Gage: 10-12.5mm
  • 78MXTZ-16   Mechanical 3-Point Bore Gage: 12.5-16mm
  • 78MXTZ-20   Mechanical 3-Point Bore Gage: 16-20mm
  • 78MXTZ-25   Mechanical 3-Point Bore Gage: 20-25mm
  • 78MXTZ-35   Mechanical 3-Point Bore Gage: 25-35mm
  • 78MXTZ-50   Mechanical 3-Point Bore Gage: 35-50mm
  • 78MXTZ-65   Mechanical 3-Point Bore Gage: 50-65mm
  • 78MXTZ-80   Mechanical 3-Point Bore Gage: 65-80mm
  • 78MXTZ-100 Mechanical 3-Point Bore Gage: 80-100mm
  • 78MXTZ-125 Mechanical 3-Point Bore Gage: 100-125m
  • 78MXTZ-150 Mechanical 3-Point Bore Gage: 125-150mm
  • 78MXTZ-175 Mechanical 3-Point Bore Gage: 150-175mm
  • 78MXTZ-200 Mechanical 3-Point Bore Gage: 175-200mm
  • 78MXTZ-225 Mechanical 3-Point Bore Gage: 200-225mm
  • 78MXTZ-250 Mechanical 3-Point Bore Gage: 225-250mm
  • 78MXTZ-275 Mechanical 3-Point Bore Gage: 250-275mm
  • 78MXTZ-300 Mechanical 3-Point Bore Gage: 275-300mm

Sets:

  • S78MXTAZ Mechanical 2-Point Bore Gage Set: 2-3mm
  • S78MXTBZ Mechanical 2-Point Bore Gage Set: 3-6mm
  • S78MXTCZ Mechanical 3-Point Bore Gage Set: 6-10mm
  • S78MXTDZ Mechanical 3-Point Bore Gage Set: 10-20mm
  • S78MXTEZ Mechanical 3-Point Bore Gage Set: 20-50mm
  • S78MXTFZ Mechanical 3-Point Bore Gage Set: 50-100mm
