Profile Projectors

Quick Answer

A profile projector (also called an optical comparator) is a precision optical instrument that projects a magnified silhouette of a part onto a screen for dimensional measurement and profile comparison. Profile projectors are used in manufacturing and quality control to measure the geometry, contour, and dimensions of small or complex parts that are difficult to inspect with contact gages — including threads, gear teeth, cutting tools, stamped parts, and formed profiles.
