Vision Fixtures

Quick Answer

A vision fixture is a workholding and positioning device designed to accurately locate and secure parts on a vision measuring system, optical comparator, or other optical inspection instrument. Proper vision fixturing ensures repeatable, consistent part presentation to the camera or optical system, which is essential for accurate, reproducible measurement results in non-contact optical inspection.
