TMX 3-842-3200P 4-Jaw VTL Scroll Chuck
Product Code: 3-842-3200PMFGID: 3-842-3200P
Brand: TMX
Product Description
3-842-3200P TMX 4-Jaw VTL Scroll Chuck: 32″
The TMX 3-842-3200P 4-Jaw VTL Scroll Chuck has the following specifications:
- Size: 32″
- # of Jaws: 4
- B: 6.57″
- C: 29.92″
- D: 28.74″
- F: 2.8″
- H: 6xM20
- J: 5″
- L: 2.36″
- P: 0.31″
- T- Slots (no x throat width mm): 4×18
- Max Torque on Key Da.N.M: 80
- Gripping Force DAN: 12300
- Weight (lb.)*: 915
Features:
- Forged Steel Body
- Heavy Duty Steel Body
- Fitted with Wiper Seals
- Extended Master Jaws for extra rigidity
- Center Plug seals out chips and containments
- T-Slots-All sizes
Each Chuck Provided With:
- 1 Set of Hard Master Jaws
- 1 Set of Reversible Hard Top Jaws
- 1 Chuck Wrench
If this chucks page does not have the specifications or information you are searching please visit the TOOLMEX company website. You can find their website by Clicking Here.
TMX 4-Jaw VTL Scroll Chuck
- 3-842-2800P 4-Jaw VTL Scroll Chuck: 28″
- 3-842-3200P 4-Jaw VTL Scroll Chuck: 32″
- 3-842-3600P 4-Jaw VTL Scroll Chuck: 36″
- 3-842-4000P 4-Jaw VTL Scroll Chuck: 40″
- 3-842-4800P 4-Jaw VTL Scroll Chuck: 48″
- 3-842-5200P 4-Jaw VTL Scroll Chuck: 52″
- 3-842-5500P 4-Jaw VTL Scroll Chuck: 55″
- 3-842-6300P 4-Jaw VTL Scroll Chuck: 63″
- 3-842-7100P 4-Jaw VTL Scroll Chuck: 71″
