INSIZE 3353-75WL High Precision Disk Micrometer/Snap Gage
Product Code: 3353-75WLMFGID: 3353-75WL
Brand: INSIZE
Product Description
3353-75WL INSIZE High Precision Disk Micrometer/Snap Gage – Built-In Wireless: 2-3″/50-75mm
The INSIZE 3353-75WL High Precision Disk Micrometer/Snap Gage – Built-In Wireless has the following specifications:
- Range: 2-3″/50-75mm
- Accuracy: ±.00007″
- Repeatability: .00004″
- Flatness: .00002″
- Parallelism: .00004″
- A: 3.464″
- B: 1.772″
Features:
- Absolute encoder, the original data remains after power off.
- Adjustable Resolution: 0.0002mm/0.00001″, 0.001/0.00005″, 0.01/0.0005″
- One turn of sleeve makes 5mm spindle feed
- Measurement Accuracy is not affected by the use of sleeve
- Press the fork, the spindle retracts 3mm
- Linear ball bearings for ten million times use
- Carbide spindle and anvil
- Measuring force 7-10N
- Customizable measuring force range 2-12N. Attention: small measuring force will reduce the dustproof and waterproof level
- Button function: data output, tolerance, data preset, data hold, measuring direction, max./min./TIR, power-off time, on/off, zero, mm/inch, adjust resolution
- Supplied with gage blocks for zero setting
- Power: rechargeable battery, for 24 hours continuous working
- Data output
- IP65 waterproof
- Non – rotating
- Supplied with manufacturer inspection certificate
If this micrometers page does not have the specifications or information you are searching please visit the INSIZE company website. You can find their website by Clicking Here.
INSIZE High Precision Disk Micrometer/Snap Gages – Built-In Wireless
- 3353-25WL High Precision Disk Micrometer/Snap Gage – Built-In Wireless 0-1″/0-25mm
- 3353-50WL High Precision Disk Micrometer/Snap Gage – Built-In Wireless 1-2″/25-50mm
- 3353-75WL High Precision Disk Micrometer/Snap Gage – Built-In Wireless 2-3″/50-75mm
- 3353-100WL High Precision Disk Micrometer/Snap Gage – Built-In Wireless 3-3.925″/75-100mm
