Metric Digital Screw Thread Micrometers – Tips Included
Product Code: 3581-S25MFGID: 3581-S25
Brand: INSIZE
Product Description
3581-S25 INSIZE Metric Digital Screw Thread Micrometer – Tips Included: 0-1″
The INSIZE 3581-S25 Metric Digital Screw Thread Micrometer – Tips Included has the following specifications:
- Range: 0-1″
- Range(mm): 0-25mm
- Length: 42mm
- b: 26mm
- Measuring tips included: 6 pairs of measuring tips: metric and unified thread (60° thread angle) 0.4-0.5mm/64-48TP, 0.6-0.9mm/44-28TP, 1-1.75mm/24-14TP, 2-3mm/13-9TPI, 3.5-5mm/8-5TPI, 5.5-7mm/4.5-3.5TPI
Features:
- Measure pitch diameter of screw threads
- Resolution 0.001mm/0.00005″
- Button function: on/off, set, mm/inch, ABS/INC
- Data output
- Automatic power off
- Non-rotating spindle
- Ratchet stop
- Supplied with 60° setting standards (except 0-25mm/0-1 “)
- Optional accessary: 55° setting standards,
- data output cable (code 7315-30, 7302-30)
If this micrometers page does not have the specifications or information you are searching please visit the INSIZE company website. You can find their website by Clicking Here.
INSIZE Metric Digital Screw Thread Micrometer – Tips Included
- 3581-S25 Metric Digital Screw Thread Micrometer – Tips Included 0-1″
- 3581-S50 Metric Digital Screw Thread Micrometer – Tips Included 1-2″
- 3581-S75 Metric Digital Screw Thread Micrometer – Tips Included 2-3″
- 3581-S100 Metric Digital Screw Thread Micrometer – Tips Included 3-4″
- 3581-S125 Metric Digital Screw Thread Micrometer – Tips Included 4-5″
- 3581-S150 Metric Digital Screw Thread Micrometer – Tips Included 5-6″
- 3581-S175 Metric Digital Screw Thread Micrometer – Tips Included 6-7″
- 3581-S200 Metric Digital Screw Thread Micrometer – Tips Included 7-8″
