Mitutoyo MicrometersMitutoyo 141-012 Carbide Tipped Inside Micrometer: 8-9″

Mitutoyo 141-012 Carbide Tipped Inside Micrometer: 8-9″

Name: 141-012 Mitutoyo Carbide Tipped Inside Micrometer: 8-9" - Call 800-469-0132 or Buy Online
SKU: 141-012

Product Code: 141-012

MFGID: 141-012

Brand: Mitutoyo

Range: 8- 9"

Travel of Micrometer Head: 1"

Product Description

141-012 Mitutoyo Carbide Tipped Inside Micrometer: 8-9″

The Mitutoyo 141-012 Carbide Tipped Inside Micrometer has the following specifications:

Range: 8-9″

Travel of Micrometer Head: 1″

Accuracy: +/-{.00024+ (.00004xR/2)}” R=Maximum measuring length (inch) Fraction rounded up

Graduation: 0.01mm or .001″

Micrometer head only

Features:

With locking clamp.

Each interchangeable rod is marked with its measuring range.

The sizes of interchangeable rods can be adjusted with spacing collars.

Both micrometer head and furnished rods are satin-chrome finished throughout.

Supplied in fitted plastic case. Over 1000mm / 40″ supplied in wooden case.

Inside Micrometers Carbide Tipped – Interchangeable-Rod Type – Inch

141-004 Inside Micrometer Carbide Tipped: 1-1.25″

141-104 Inside Micrometer Carbide Tipped: 1-2″

141-028 Inside Micrometer Carbide Tipped: 2-2.5″

141-214 Inside Micrometer Carbide Tipped: 2-8″

141-215 Inside Micrometer Carbide Tipped: 2-12″

141-012 Inside Micrometer Carbide Tipped: 8-9″

Inside Micrometers – Interchangeable-Rod Type – Inch

141-002 Inside Micrometer: 1-1.25″

141-102 Inside Micrometer: 1-2″

141-026 Inside Micrometer: 2-2.5″

141-208 Inside Micrometer: 2-8″

141-233 Inside Micrometer: 2-12″

141-010 Inside Micrometer: 8-9″

141-121 Inside Micrometer: 8-20″

141-122 Inside Micrometer: 8-40″
