Mitutoyo 172-014 PH-A14 Profile Projector: 100X Projection Lens
Product Code: 172-014MFGID: 172-014
Brand: Mitutoyo
Product Description
172-014 Mitutoyo PH-A14 Profile Projector Accessory – 100X Projection Lens
The Mitutoyo 172-014Â PH-A14 Profile Projector Accessory – has the following specifications:
- Range: 100X
- Compatible with PH-A14 Profile Projector
Features:
- Benchtop model uses a horizontal optical system.
- Suitable for thread pitch measurements – blurred or distorted images will not be produced when workpiece is angled.
- Inverted image on the day-bright screen.
- 14″ (356mm) diameter vernier protractor screen with solid line cross-hairs for easy alignment.
- Heavy-duty workpiece table incorporates linear scales for fast, accurate measurement.
PH-A14 Profile Projector
- 172-810-10A PH-A14 Profile Projector
PH-A14 Profile Projector Optional Accessories
- 172-011 10X Projection Lens
- 172-012 20X Projection Lens
- 172-013 50X Projection Lens
- 172-014 100X Projection Lens
- 172-116 Standard Scale (50mm)
- 172-117 Standard Scale (2″)
- 172-118 Standard Scale (200mm)
- 172-161 Standard Scale (300mm)
- 172-119 Standard Scale (8″)
- 172-162 Standard Scale (12″)
- 172-286 Green Filter
- 512305 Halogen Bulb (24V, 150W)
