Meyer Gage L4XP Steel Pin Gage Library Set – Plus
Product Code: L4XPBrand: Meyer Gage
Product Description
L4XP Meyer Gage Steel Pin Gage Library Set Class X – Inch (plus): .011″ to 1.000″
The Meyer Gage L4XP Steel Pin Gage Library Set Class X has the following specifications:
- Range: .011″ to 1.000″
- Number of Members: 990 gages
- Weight (lbs.): 240
Offers the same features as
our Class Z pin gages, but
with 0.00004″ tolerance limits
and 0.00002″ roundness limits.
The pins are perfect for critical
inspection needs, or when you
want to maximize your GO/
NOGO tolerance limits.
They’re also a great way to
calibrate measuring
equipment, micrometers, and
calipers.
Features:
- All gages and sets are traceable to N.I.S.T.
- Boxes and gages both marked
- Size and serial number laser etched on each piece (M0X not etched)
- Material: 52100 Bearing Steel
- No sharp edges
- All members 2″ long
Uses:
- Checking locations
- Measuring hole sizes and depth
- GO & NO/GO gaging
- Setting micrometers
- Checking distances between holes
Finish:
- Centerless lapped
- Each gage is inspected and has a 2 microfinish or better
- Heat treated to a hardness of 60-62 Rockwell C
- All English gages with 0.00004″ limit
Meyer Gage Steel Pin Gage Set Class X – Inch (plus):
- M0XP Steel Pin Gage Set: .011 to .060″
- M05XP Steel Pin Gage Set: .0115 to .0605″
- M1XP Steel Pin Gage Set: .061 to .250″
- M15XP Steel Pin Gage Set: .0615 to .2505″
- C10XP Steel Pin Gage Set: .011 to .250″
- C105XP Steel Pin Gage Set: .0115 to .2505″
- M2XP Steel Pin Gage Set: .251 to .500″
- M25XP Steel Pin Gage Set: .2515 to .5005″
- M3XP Steel Pin Gage Set: .501 to .625″
- M35XP Steel Pin Gage Set: .5015 to .6255″
- M4XP Steel Pin Gage Set: .626 to .750″
- M45XP Steel Pin Gage Set: .6265 to .7505″
- M5XP Steel Pin Gage Set: .751 to .832″
- M55XP Steel Pin Gage Set: .7515 to .8325″
- M6XP Steel Pin Gage Set: .833 to .916″
- M65XP Steel Pin Gage Set: .8335 to .9165″
- M7XP Steel Pin Gage Set: .917 to 1.000″
- M75XP Steel Pin Gage Set: .9175 to 1.0005″
Meyer Gage Steel Pin Gage Class X Library Sets – Inch (plus):
- LCXP Steel Pin Gage Set: .011 to .750″
- L1XP Steel Pin Gage Set: .061 to .750″
- L2CXP Steel Pin Gage Set: .011 to .5005″
- L2XP Steel Pin Gage Set: .061 to .5005″
- L3XP Steel Pin Gage Set: .061 to 1.000″
- L4XP Steel Pin Gage Set: .011 to 1.000″
Meyer Gage Steel Pin Gage Set Class X – Inch (minus):
- M0XM Steel Pin Gage Set: .011 to .060″
- M05XM Steel Pin Gage Set: .0115 to .0605″
- M1XM Steel Pin Gage Set: .061 to .250″
- M15XM Steel Pin Gage Set: .0615 to .2505″
- C10XM Steel Pin Gage Set: .011 to .250″
- C105XM Steel Pin Gage Set: .0115 to .2505″
- M2XM Steel Pin Gage Set: .251 to .500″
- M25XM Steel Pin Gage Set: .2515 to .5005″
- M3XM Steel Pin Gage Set: .501 to .625″
- M35XM Steel Pin Gage Set: .5015 to .6255″
- M4XM Steel Pin Gage Set: .626 to .750″
- M45XM Steel Pin Gage Set: .6265 to .7505″
- M5XM Steel Pin Gage Set: .751 to .832″
- M55XM Steel Pin Gage Set: .7515 to .8325″
- M6XM Steel Pin Gage Set: .833 to .916″
- M65XM Steel Pin Gage Set: .8335 to .9165″
- M7XM Steel Pin Gage Set: .917 to 1.000″
- M75XM Steel Pin Gage Set: .9175 to 1.0005″
Meyer Gage Steel Pin Gage Class X Library Sets – Inch (minus):
- LCXM Steel Pin Gage Set: .011 to .750″
- L1XM Steel Pin Gage Set: .061 to .750″
- L2CXM Steel Pin Gage Set: .011 to .5005″
- L2XM Steel Pin Gage Set: .061 to .5005″
- L3XM Steel Pin Gage Set: .061 to 1.000″
- L4XM Steel Pin Gage Set: .011 to 1.000″
Meyer Gage Steel Pin Gage Existing Set Upgrades:
