Mitutoyo 201-104 Dial Snap Gage: 75 – 100mm
Product Code: 201-104MFGID: 201-104
Brand: Mitutoyo
Product Description
201-104 Mitutoyo Dial Snap Gage – 75 – 100mm
The Mitutoyo 201-104 Dial Snap Gage – has the following specifications:
- Range: 75 – 100mm
- Measuring force: 15+/-3N
- Parallelism: 5um or less
- Recommended dial indicator (optional): 2046SB (0.01mm reading), 2109SB-10 (0.001mm reading)
- Accuracy: Refer to the list of specifications
- Anvil retracting stroke: .078″ / 2mm
- Anvil positioning range: 1″ / 25mm
- Anvil flatness: .00004″ / 1um
Features:
- Designed for quick go/no-go judgment of diameters of cylinders and shafts in machining processes.
- Dial indicator is optional.
- Wide (.53 x .47″ / 13.5 x 12mm), flat carbide anvils
- Both front edges of the anvil are chamfered for easy insertion.
Dial Snap Gages – Metric
- 201-101 Dial Snap Gage: 0-25mm
- 201-102 Dial Snap Gage: 25-50mm
- 201-103 Dial Snap Gage: 50-75mm
- 201-104 Dial Snap Gage: 75-100mm
- 201-105 Dial Snap Gage: 100-125mm
- 201-106 Dial Snap Gage: 125-150mm
- 201-107 Dial Snap Gage: 150-175mm
- 201-108 Dial Snap Gage: 175-200mm
- 201-109 Dial Snap Gage: 200-225mm
- 201-110 Dial Snap Gage: 225-250mm
- 201-111 Dial Snap Gage: 250-275mm
- 201-112 Dial Snap Gage: 275-300mm
Dial Snap Gages – Inch
- 201-151 Dial Snap Gage 0-1″
- 201-152 Dial Snap Gage 1-2″
- 201-153 Dial Snap Gage 2-3″
- 201-154 Dial Snap Gage 3-4″
- 201-155 Dial Snap Gage 4-5″
- 201-156 Dial Snap Gage 5-6″
- 201-157 Dial Snap Gage 6-7″
- 201-158 Dial Snap Gage 7-8″
- 201-159 Dial Snap Gage 8-9″
- 201-160 Dial Snap Gage 9-10″
- 201-161 Dial Snap Gage 10-11″
- 201-162 Dial Snap Gage 11-12″
