Mahr 2050979 MaraMeter Portable Thickness Gage: 0-12.5mm
Product Code: 2050979MFGID: 2050979
Brand: MAHR
Product Description
2050979 Mahr MaraMeter Portable Thickness Gage: 0 – 12.5mm
The Mahr 2050979 MaraMeter Portable Thickness Gage has the following specifications:
- Measuring Range: 0 – 12.5mm
- Throat Depth: 106mm
- Graduation Value: 0.01mm
- Indicating Instrument: IDS- 286 Indicator (SQ6I)
Features:
- Solid casting with ribbed frame provides strength and rigidity for accurate measurements.
- Gage is furnished with a lift lever so work can be easily placed between the contacts.
- Large 54 mm/ 2.125″ diameter lower anvil provides convenient stage for small parts or flat materials.
- 4.75 mm/ .187″ diameter radiused upper contact normally provided.
- 102 mm/ 4″ throat depth for part clearance.
- Indicator mounts with adjustable back for quick positioning for each gaging requirement.
- Available with Dial Indicator or Digital Electronic Indicator.
- Data interface: none.
- Energy supply: Battery operation.
- Scope of delivery: Includes Indicator.
Application:
- Precision Thickness Measurement.
Mahr MaraMeter Portable Thickness Gages 57B-11M / 57B-12M:
- 2050977 MaraMeter Portable Thickness Gage: 0-25mm
- 2050979 MaraMeter Portable Thickness Gage: 0-12.5mm
Mahr MaraMeter Portable Thickness Gages 57B-11 / 57B-12:
