Mahr 4190315 Self-Centering Inside Micrometer: 20-25mm
Product Code: 4190315MFGID: 4190315
Brand: MAHR
Product Description
4190315 Mahr Self-Centering Inside Micrometer: 20-25mm
The Mahr 4190315 Self-Centering Inside Micrometer has the following specifications:
- Measuring Range: 20-25mm
- Measuring Depth: 68 / (218**)mm
- Readings: 0.005mm
- Error Limit G*: 4?m
Features:
- Scales with satin-chrome finish
- Spindle is hardened throughout and ground
- Rapid drive with integrated ratchet
- Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120°
- Anvils from 12 mm are carbide tipped
- From 12 mm the anvils can be used to measure to the bottom of a bore
- From 40 mm all measuring heads are made from aluminum to reduce weight
- Supplied with: Case and operating instructions
Mahr Self-Centering Inside Micrometers:
- 4190310 Self-Centering Inside Micrometer: 6-8mm
- 4190311 Self-Centering Inside Micrometer: 8-10mm
- 4190312 Self-Centering Inside Micrometer: 10-12mm
- 4190313 Self-Centering Inside Micrometer: 12-16mm
- 4190314 Self-Centering Inside Micrometer: 16-20mm
- 4190315 Self-Centering Inside Micrometer: 20-25mm
- 4190316 Self-Centering Inside Micrometer: 25-30mm
- 4190317 Self-Centering Inside Micrometer: 30-40mm
- 4190319 Self-Centering Inside Micrometer: 50-60mm
- 4190320 Self-Centering Inside Micrometer: 60-70mm
- 4190012 Self-Centering Inside Micrometer: 70-85mm
- 4190013 Self-Centering Inside Micrometer: 85-100mm
- 4190014 Self-Centering Inside Micrometer: 100-125mm
- 4190015 Self-Centering Inside Micrometer: 125-150mm
- 4190016 Self-Centering Inside Micrometer: 150-175mm
- 4190017 Self-Centering Inside Micrometer: 175-200mm
Mahr Self-Centering Inside Micrometer Sets:
