  • Product Code: #4190014

    Self-Centering Inside Micrometer - # 4190014

    Measuring range: 100 - 125mm

    Measuring depth: 132 / (282**)mm

    Price: $1,100.00 $1,045.00
    Lowest Price Guaranteed
    Quantity

    Product Description

    4190014 Mahr Self-Centering Inside Micrometer: 100-125mm

    The Mahr 4190014 Self-Centering Inside Micrometer has the following specifications:

    • Measuring Range: 100-125mm
    • Measuring Depth: 132 / (282**)mm
    • Readings: 0.005mm
    • Error Limit G*: 6μm

    Features:

    • Scales with satin-chrome finish
    • Spindle is hardened throughout and ground
    • Rapid drive with integrated ratchet
    • Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120°
    • Anvils from 12 mm are carbide tipped
    • From 12 mm the anvils can be used to measure to the bottom of a bore
    • From 40 mm all measuring heads are made from aluminum to reduce weight
    • Supplied with: Case and operating instructions

    Mahr Self-Centering Inside Micrometers:

    • 4190310 Self-Centering Inside Micrometer: 6-8mm
    • 4190311 Self-Centering Inside Micrometer: 8-10mm
    • 4190312 Self-Centering Inside Micrometer: 10-12mm
    • 4190313 Self-Centering Inside Micrometer: 12-16mm
    • 4190314 Self-Centering Inside Micrometer: 16-20mm
    • 4190315 Self-Centering Inside Micrometer: 20-25mm
    • 4190316 Self-Centering Inside Micrometer: 25-30mm
    • 4190317 Self-Centering Inside Micrometer: 30-40mm
    • 4190319 Self-Centering Inside Micrometer: 50-60mm
    • 4190320 Self-Centering Inside Micrometer: 60-70mm
    • 4190012 Self-Centering Inside Micrometer: 70-85mm
    • 4190013 Self-Centering Inside Micrometer: 85-100mm
    • 4190014 Self-Centering Inside Micrometer: 100-125mm
    • 4190015 Self-Centering Inside Micrometer: 125-150mm
    • 4190016 Self-Centering Inside Micrometer: 150-175mm
    • 4190017 Self-Centering Inside Micrometer: 175-200mm

    Mahr Self-Centering Inside Micrometer Sets:

    • 4190350 Self-Centering Inside Micrometer Set: 6-12mm
    • 4190351 Self-Centering Inside Micrometer Set: 12-20mm
    • 4190352 Self-Centering Inside Micrometer Set: 20-50mm
    • 4190353 Self-Centering Inside Micrometer Set: 50-100mm
  •
